Commercial Full Color IP65 Outdoor LED Signs Wall Mouted with Frame LED Box

Name: Commercial Full Color IP65 Outdoor LED Signs Wall Mouted with Frame LED Box
Brand: Dreamway
Price: 1 USD

China Commercial Full Color IP65 Outdoor LED Signs Wall Mouted with Frame LED Box wholesale

Place of Origin : China

Brand Name : Dreamway

Certification : CE,ROHS

Model Number : P16

MOQ : negotiable

Price : negotiable

Packaging Details : Plywood case

Delivery Time : 20 days after receiving the deposit

Payment Terms : T/T

Supply Ability : 2000sq.m/Month

Contact Now

Outdoor LED Signs PH16 2R1G1B with Frame LED Box of IP65 Grade

Quick Detail:

1. 2R1G1B;
2. 16 by 8 dots per module;
3. 256 by 128 mm LED module dimension;
4. All Epistar LED package;
5. Static scanning;
6. MBI5024 driving IC.

Detail Description:

Static scan LED module is more bright than other scanning module;
More than 7500 nits per square meter;
Xixun M20 controller, with 500 megabyte memory and could be extended by USB.

Application:

It is front service, mouted on the wall generally for advertising.

Specifications:

Type	P 16
LED Composition	2R1G1B
LED Type	DIP546
Pixel	3,906 dots/sq.m
LED Module Pixel	W 16 × H 8
LED Module Size	W 256 × H 128 mm
Service Way	Front maintain
Cabinet Color	Black
Cabinet Material	IP65 Steel waterproof
Driving Method	Static scan
Luminance	More than 7500 nits/sq.m
Refresh Rate	More than 200Hz
Out of Control Dot Rate	＜0.0001
Earth Leakage Current	＜2mA
MTBF	＞5,000 hours
LED Life Span	＞100,000 hours
Power Source	110V/60HZ and 220V/50HZ interchangeable
Brand	Meanwell
Operation Software	LEDEditor_V9
Operation System	Win2000 / XP / Vista

Commercial Full Color IP65 Outdoor LED Signs Wall Mouted with Frame LED Box

USA Outdoor LED Signs, High Performance Outdoor LED Signs, Outdoor LED Signs with Front Service
